USE:
Suitable for all kind of paper tube / paper can production. Such as package tin, tea caddy,
food cans, wine cans, fireworks tube, calendar tube, fax paper core, etc.
FEATURE:
1.Low price, strong practicability, stable performance;
2.Automatically cut, automatically fall pipe, automatically change speed and revert;
3.Computer PLC control, touch screen man-machine interface operation;
4.Round knife cutting, incision more smooth, performance more stable;
5.With polyurethane scraper and high carbon steel plastic knife, durable in use;
6.Automatically glue.
Technical Parameter | Control System |
Number of roller | 3-8 layer | PLC controller | Delta DVP14SS2 |
Tube diameter | 15-150 mm | Touch screen | MCGS TPC7062 |
Tube wall-thickness | 0.5-5 mm | Inverter | SANJING |
Core mould fixed way | Flank | Electric part | CHINT |
Winding head | 2 | Signal part | SHHG |
Cutting way | Round knife | Pneumatic part | AIRTAC |
Gluing way | Single / Double sides | Fix length way | Optoelectronic switch |
Operator | 1-2 person | Equip device |
Winding speed | 3-20 m/min | Paper reel stand | Crisscross 8-layer |
Speed control | Inverter | Auto fall tube shelf | Have |
Driving System | Glue system | 8-layer |
Main motor | 4.0 KW | Belt | 2 |
Reducer type | RV series | Core mould | 2 |
Cutting motor | Wanxin | Mainframe size | 2500*1600*2000 mm |
Glue pump | 750W | Weight | 1500 KG |
Area space | 8000*6000 mm |
